| Last time: Finished 7.2, and started 7.3 (Minimization). | Next time: review for exam 2 |
Today:
Links:
"The 4-bit adder we just created is called a ripple-carry adder. It gets that name because the carry bits "ripple" from one adder to the next. This implementation has the advantage of simplicity but the disadvantage of speed problems. In a real circuit, gates take time to switch states (the time is on the order of nanoseconds, but in high-speed computers nanoseconds matter). So 32-bit or 64-bit ripple-carry adders might take 100 to 200 nanoseconds to settle into their final sum because of carry ripple. For this reason, engineers have created more advanced adders called carry-lookahead adders. The number of gates required to implement carry-lookahead is large, but the settling time for the adder is much better."
