Wallpaper Groups

Symmetry group 2 (p2)

This group differs only from the first group in that it contains 180° rotations, that is, rotations of order 2, also called "half-turns." As in all symmetry groups there are translations, but there are no reflections or glide-reflections. The two translation axes may be inclined at any angle to each other. The lattice is a parallelogrammatic. A fundamental region for the symmetry group is half of a parallelogram that is a fundamental region for the translation group.

It may be a little difficult to see the half-turns, so their fixed points are covered with black dots in this image. Half-turn symmetries are subtile and aren't very easy to find. Note that in this example (as in all patterns with this symmetry) there are four essentially different centers of half-turns.
