Wallpaper Groups

Symmetry group 8 (pgg)

This group contains no reflections, but it has glide-reflections and half-turns. There are perpendicular axes for the glide-reflections, and the fixed points of the half-turns do not lie on these axes. Again, the lattice is rectangular, and a quarter-rectangle of a fundamental region for the translation group is a fundamental region for the symmetry group..

In the image on the right, the fixed points of the half-turns are indicated by black dots, and the axes of the glide-reflections are drawn in green.


Up to the 17 wallpaper groups
Back to the previous wallpaper group
On to the next wallpaper group
